Description

The FSR 402 from Interlink Electronics is a compact and reliable force sensing resistor designed for precise touch control and pressure measurement. With its polymer thick film (PTF) technology, the FSR 402 provides accurate force readings by decreasing resistance as pressure is applied. Its small 18.28 mm diameter and thin profile (0.45 mm) make it ideal for applications in diverse industries such as automotive, medical devices, consumer electronics, and industrial systems. It offers a robust, repeatable, and cost-effective solution for integrating force sensing into electronic devices.

Key Features & Benefits

• Low Actuation Force: Detects forces as small as 0.1 Newtons.
• Wide Sensitivity Range: Measures forces from 0.1 to 10 Newtons.
• Highly Repeatable: Accurate within ±2% of initial readings for consistent performance.
• Ultra-Thin: Only 0.45mm thick, ideal for space-constrained applications.
• Long Life: 10 million actuations without failure.
• Customizable: Available in various sizes, from 5mm to over 600mm.

Applications

• Human-Machine Interface (HMI): For touch controls in devices like game controllers, medical systems, and automotive panels.
• User Feedback: Provides tactile force feedback in musical instruments and consumer electronics.
• Safety Systems: Differentiates between touch and grip for safety features in tools and locks.
• Medical Monitoring: Detects patient presence or movement in medical devices and hospital settings.
• Industrial Systems: Measures back pressure, detects tube blockages, and monitors force in machinery.

Specifications

• Actuation Force: 0.1 Newtons (min.)
• Force Sensitivity Range: 0.1 to 10.02 Newtons
• Force Repeatability (Single Part): ±2%
• Size: 18.28mm diameter
• Thickness Range: 0.2 to 1.25mm
• Rise Time: <3 microseconds
• Operating Temperature: -30°C to +70°C
• Lifetime: 10 million actuations
• Non-Actuated Resistance: 10MΩ
