LAN8720 Ethernet Transceiver Modules RMII Interface

Description:

LAN8720 Ethernet Transceiver Module RMII Interface

Boost your electronic projects with the LAN8720 Ethernet Transceiver Module RMII Interface, a compact and efficient solution for adding Ethernet connectivity to your designs. This high-performance module is ideal for developers, hobbyists, and engineers looking to integrate reliable network communication into their microcontroller-based systems. With its straightforward setup and robust capabilities, the LAN8720 module ensures a seamless connection to the digital world.

Choosing the LAN8720 Ethernet Transceiver Module RMII Interface means opting for a reliable, easy-to-integrate solution that enhances the connectivity of your electronic projects. Whether you’re developing IoT devices, working with microcontrollers, or building embedded systems, this module provides the robust network performance you need to bring your ideas to life.

Key Features & Benefits:

• Reliable Ethernet Connectivity: The LAN8720 module provides stable and fast Ethernet communication, supporting both 10 Mbps and 100 Mbps data rates. This makes it perfect for applications requiring efficient data transfer and network reliability.
• RMII Interface Compatibility: Featuring a Reduced Media Independent Interface (RMII), this module is designed for easy integration with a wide range of microcontrollers and development boards. It simplifies the process of adding Ethernet capabilities to your projects.
• Compact Design: With its small footprint, the LAN8720 module is an excellent choice for space-constrained applications. Its lightweight and compact design make it easy to incorporate into any electronic project without adding bulk.
• Low Power Consumption: Optimized for low power usage, the LAN8720 helps reduce energy consumption in your designs. This is particularly beneficial for battery-operated devices and projects where energy efficiency is a priority.
• Wide Operating Temperature Range: Built to withstand various environmental conditions, the LAN8720 module operates reliably across a wide temperature range, ensuring stable performance in different applications.

Applications:

The LAN8720 Ethernet Transceiver Module is versatile and can be used in a variety of electronic projects, including:

• Microcontroller-Based Projects: Ideal for adding Ethernet connectivity to microcontroller-based systems, making it easier to connect devices to a network for data exchange, remote control, and monitoring.
• IoT (Internet of Things) Devices: Perfect for integrating into IoT devices that require reliable network communication. It enables seamless connectivity for smart home systems, industrial automation, and other IoT applications.
• Development Boards: Suitable for use with various development boards, allowing developers to prototype and test Ethernet-enabled applications quickly and efficiently.
• Embedded Systems: Great for embedded systems where network connectivity is essential for operation. This includes digital signage, networked sensors, and other embedded applications that rely on Ethernet communication.

Specifications:

• Model: LAN8720 Ethernet Transceiver Module
• Interface: RMII (Reduced Media Independent Interface)
• Data Rate: Supports both 10 Mbps and 100 Mbps Ethernet connectivity
• High-performance 10/100 Ethernet transceiver (PHY)
• Ultra-low-power design, you can use a single 3.3V power supply
• Using RMII interface, greatly reducing the MCU control pins
• Support HP Auto-MIDX
• Chip 24-pin QFN package (4×4 mm), lead-free
• Flexible power management architecture
• Integrated 1.2V regulator
• IO voltage range: + 1.6V to + 3.6V

Enhance your projects with the LAN8720 Ethernet Transceiver Module RMII Interface. Order now to enjoy reliable Ethernet connectivity and take your designs to the next level!
