Raspberry Pi 8-Channel ADC Shield

Description

The 8-Channel 12-Bit ADC Shield for Raspberry Pi is a powerful and versatile accessory designed to expand the capabilities of your Raspberry Pi projects. Built around the STM32F030 ARM Cortex M0 MCU, this shield enables precise analog-to-digital conversion through its eight integrated ADC channels. With easy connectivity via connectors, it’s perfect for a wide range of applications, from data acquisition to environmental monitoring.

Key Features & Benefits

• High Resolution: 12-bit ADC for accurate data conversion.
• Integrated  Connectors: Easy integration with modules.
• Low Power Consumption: Efficient STM32F030 MCU design.
• Advanced Timing Support: Built-in RTC and multiple timers for precise control.

Applications

• Temperature Monitoring: Ideal for capturing and logging temperature data.
• IoT Projects: Perfect for smart home devices and sensor networks.
• Educational Use: Great for learning about analog signal processing and electronics.

Specifications

• Operating Voltage: 3.3 V
• ADC Resolution: 12-bit
• Maximum Clock Frequency: 48 MHz
• Program Memory Size: 16 kB
• Data RAM Size: 4 kB
• Data Bus Width: 32-bit
• Operating Temperature Range: -40 to 85°C
• Communication Interfaces: I2C
• I2C Address: 0x04 (default)
