Description:
ENC28J60 Ethernet Network Module – SPI Interface
The ENC28J60 Ethernet Network Module is an efficient and cost-effective solution for adding Ethernet connectivity to your embedded systems and microcontroller projects. Powered by the Microchip ENC28J60 Ethernet controller, this module allows your device to communicate over Ethernet networks using the SPI (Serial Peripheral Interface), making it an ideal choice for IoT devices, smart home projects, and remote monitoring systems.
This module is perfect for integrating with popular development platforms such as Arduino, Raspberry Pi, ESP32, and STM32, offering seamless and stable network connections. The ENC28J60 module is widely used for creating lightweight, low-cost network devices that require basic TCP/IP functionality.
Applications:
- 3D Printers: Enable Ethernet connectivity for remote control and monitoring.
- IoT Devices: Connect Internet of Things devices to a local or wide-area network.
- Home Automation: Power smart home systems and appliances with Ethernet access.
- Embedded Systems: Add reliable Ethernet networking to microcontroller-based projects.
Specifications:
- Chipset: ENC28J60 Ethernet controller
- Interface: SPI (Serial Peripheral Interface)
- Ethernet Speed: 10Mbps Ethernet
- Voltage: 3.3V (operates at low power consumption)
- Network Protocols: Supports full-duplex and half-duplex communication
- Data Protocols: TCP, UDP, IP, ICMP, IPv4
- Network Standards: IEEE 802.3 (Ethernet standard)
- Pins:
- VCC: 3.3V power input
- GND: Ground
- SCK: Serial Clock
- MOSI: Master Out Slave In
- MISO: Master In Slave Out
- CS: Chip Select
- RST: Reset
- INT: Interrupt pin
- PCB Size: Compact form factor for easy integration
- Compatibility: Arduino, ESP8266, ESP32, STM32, Raspberry Pi
This Ethernet module is the perfect option for any project where low-cost and efficient network communication is required. With its compact design and SPI interface, the ENC28J60 module is ideal for hobbyists and professionals alike, allowing you to quickly and easily add Ethernet capabilities to your embedded systems. Whether you’re working on a 3D printer that requires network connectivity or an IoT device that needs to communicate with the cloud, this module provides the reliability and performance your project demands.
