GY-NEO-7M V2 GPS Module for Flight Control & Navigation

GY-NEO-7M V2 GPS Module for Flight Control & Navigation

The GY-NEO-7M V2 is a high-precision GPS module based on the Ublox NEO-7M GPS chipset. It’s a popular choice for drones, RC vehicles, flight controllers (like APM, PX4, and Arduino-based systems), and other embedded navigation projects. With quick satellite lock, high sensitivity, and built-in EEPROM for configuration saving, this module is reliable, compact, and ready for real-time location tracking.

Applications:

• Drone & UAV flight navigation

• RC car and boat GPS tracking

• Telemetry systems

• Arduino GPS projects

• Real-time outdoor tracking

• Robotics navigation

• DIY positioning devices

Features:

• Equipped with Ublox NEO-7M high-performance GPS chip

• Built-in ceramic active antenna for stable signal reception

• Integrated EEPROM for storing configuration data

• Includes onboard 3.3V voltage regulator

• Fast acquisition and tracking of satellites

• TTL serial interface (compatible with 3.3V and 5V systems)

• LED indicator for GPS fix status

• Plug-and-play with most flight controllers and Arduino boards

• 6-pin header and pre-soldered wires for easy connection

Technical Specifications:

• Model: GY-NEO-7M V2

• Chipset: Ublox NEO-7M

• Antenna Type: Ceramic patch antenna (active)

• Communication Interface: UART (TTL Level)

• Baud Rate (default): 9600 bps

• Positioning Accuracy: 2.5 meters CEP

• Cold Start Time: ~27 sec

• Warm Start Time: ~25 sec

• Hot Start Time: ~1 sec

• Update Rate: 1Hz (default), configurable up to 5Hz

• Operating Voltage: 3.3V–5V

• Operating Current: ~45mA

• EEPROM: Yes (for parameter saving)

• Fix Indicator: Onboard LED

• Module Dimensions: Approx. 25mm x 35mm

• Cable Length: Approx. 25cm

• Get 51 Arduino STM32 microcontroller routine
•  with a USB interface, you can watch the computer positioning effect directly phone line.
•  with the passive ceramic antenna and passive antenna amplifier, make better use of the individual effects.
• with SMA interface can be directly connected to an active antenna SMA
• Size:39*25.5mm
• Type : Voltage Regulator
• Condition : New
• Application : Computer
• Supply Voltage : 1
• Dissipation Power : 1
• is_customized : Yes
• Interface: RS232 TTL
• Power: 3-5v
