Description

The HX711 Digital Weight Sensor Module is an A/D converter designed to interface with load cell sensors to provide accurate weight and pressure measurements. With a 24-bit resolution, the module converts the analog signal from the load cell into a digital signal for precise, reliable data output. Ideal for industrial weighing systems, tensile testing machines, and process control, this module offers strong anti-interference protection and easy parameter setting with a 4-key interface, making it a versatile solution for weighing applications.

Key Features & Benefits

• High Accuracy: 24-bit A/D conversion for precise weight measurements.
• Dynamic & Static Weighing: Supports both static and dynamic weighing modes.
• Built-in HX711 Chip: Ensures easy calibration and on-site debugging.
• Protection Features: Includes anti-reverse, anti-overvoltage, and transient suppression.
• Compact & Portable: Small size with Micro Android interface for easy power supply.
• Versatile Communication: Sends digital weight data via serial or when weight changes.

Applications

• Weighing Systems: Electronic scales, industrial weight monitoring, and displays.
• Tensile Testing Machines: Accurate load measurement for material testing.
• Process Control Instruments: Used for automatic control in industrial applications.
• Mechanical Strength Testing: Measures the strength and performance of materials.

Specifications

• Chip: HX711 A/D Converter
• Power Supply: 5VDC
• Measuring Signal Range: ±19mV
• A/D Conversion Rate: 6.25–100Hz (default: 30Hz)
• Temperature Coefficient: ≤100ppm/°C
• Sensor Compatibility: Supports up to 4,350 load cells
• Protection Features: Anti-reverse, anti-overvoltage, and transient suppression
• Display: 4-digit digital tube with adjustable decimal point
• Keypad: 4 buttons for parameter setting and calibration
• Dimension: 55 x 35 x 12 mm
