IPX to SMA Female Antenna Adapter With SMA Male Antenna 2.4GHz

Description:

The 2.4GHz IPX to SMA Female Antenna Adapter with SMA Male Antenna is a versatile solution for enhancing wireless signal performance in various applications, such as IoT devices, routers, drones, and wireless communication systems. This product allows you to seamlessly connect your devices with IPX interfaces to external SMA antennas, offering improved range and signal stability.

Designed for ease of integration, this adapter enables devices with built-in IPX connectors to use an external antenna, which is essential for improving the performance of embedded wireless systems. The accompanying 2.4GHz SMA Male Antenna delivers strong signal reception, making it ideal for Wi-Fi, Bluetooth, and other 2.4GHz frequency communications.

Applications:

• IoT Devices: Improves signal strength for better connectivity and range in smart home devices and sensors.
• Routers and Wireless Access Points: Enhances wireless range and stability by allowing the use of external antennas.
• Drones and UAVs: Optimizes signal transmission for remote control and real-time data exchange.
• Embedded Systems: Adds flexibility to wireless communication systems by enabling external antenna connectivity.


  Electrical Specifications:

  • Frequency Range (MHz): 2400-2500
  • Gain (dBi): >2.5
  • V.S.W.R.: <1.5
  • Polarization: Vertical
  • Non-Circularity (dB): ±0.5
  • Impedance (Ω): 50
  • Lightning Protection: Direct Ground
  • Maximum Input Power (W): 50

  Mechanical Specifications:

  • Connector Type: SMA
  • Radiating Element Material: Copper
  • Material: EVA
  • Dimension (mm): 110(Unbend) 92(Bend)
  • Tailing Cable Length (mm): 100/120/200
  • Packing Size (mm): 295×110×60
  • Weight (Kg): 0.009/12
  • Application Condition: Indoor
  • Operating Temperature (℃): -40~+70
  • Reposition Temperature (℃): -55~+80
  • Connector Type: IPX to SMA Female Adapter, SMA Male Antenna
  • Compatibility: Suitable for routers, access points, IoT devices, and wireless modules

  Note:

  • V.S.W.R. stands for Voltage Standing Wave Ratio, which is a measure of how well a load (like an antenna) matches the source (like a transmitter).
  • dBi is a unit of measurement for antenna gain, which indicates how much an antenna amplifies a signal compared to an isotropic radiator.
  • EVA is a type of foam often used as a dielectric material.Frequency Range (MHz):

This 2.4GHz IPX to SMA Adapter with SMA Male Antenna is designed to enhance the performance of your wireless communication systems. Whether you need to improve the Wi-Fi range of a router, boost the signal on an IoT device, or ensure reliable connectivity in drones, this antenna adapter offers a practical and efficient solution.
